AVAIN LABS® Water Bath Rectangular Double Walled

The AVAIN LABS® Water Bath Rectangular Double Walled is a high-performance laboratory heating instrument designed for precise temperature-controlled applications in research laboratories, pharmaceutical industries, educational institutions, hospitals, microbiology laboratories, and industrial testing facilities. Engineered for reliability, uniform heating, and long service life, this water bath is ideal for sample incubation, reagent warming, microbiological studies, and various scientific applications requiring accurate temperature maintenance.

The unit features a robust double-walled construction with an inner chamber manufactured from high-quality SS 202/304 grade stainless steel, ensuring excellent corrosion resistance, hygiene, and durability. The outer body is fabricated from Mild Steel (MS) and finished with premium-grade powder coating, providing superior protection against rust, wear, and harsh laboratory environments.

For enhanced thermal efficiency, the space between the inner and outer walls is insulated with high-quality glass wool insulation, minimizing heat loss and ensuring stable temperature retention while improving energy efficiency.

The inner chamber is fitted with a high-performance immersion type heating element that delivers rapid, uniform, and consistent heating across the entire chamber. Temperature regulation is achieved through a precision hydraulic capillary thermostat, allowing smooth control from ambient temperature up to 100°C with an accuracy of ±1°C for dependable laboratory performance.

The water bath offers reliable thermostatic temperature control up to 99.8°C and operates on a standard 220–230V AC power supply, making it suitable for use in laboratories and industrial environments.

Key Features

• Double-walled rectangular construction for improved thermal efficiency.
• Inner chamber made from SS 202/304 Grade Stainless Steel.
• Outer body constructed from powder-coated Mild Steel (MS).
• High-quality glass wool insulation for minimal heat loss.
• Efficient immersion type heating element for uniform heating.
• Hydraulic capillary thermostat for precise temperature control.
• Temperature range from ambient to 100°C.
• Temperature accuracy of ±1°C.
• Thermostatic temperature control up to 99.8°C.
• Operates on 220–230V AC power supply.
• Suitable for laboratory, pharmaceutical, research, educational, and industrial applications.

Premium Construction Option

Note: Rates mentioned are for the thermostat-controlled model.

Premium configuration available with:

• SS 304 Stainless Steel Inner Chamber
• 20 Gauge Outer Body Construction
• High-Grade Powder Coated Finish
• Superior Quality Components and Parts for enhanced durability and long operational life.
